JTRF2020 Solution

Earth Orientation Parameters

WARNING

The UT1 and LOD values included in the IVS submission to ITRF2020 and that were used to produce JTRF2020 included anomalous tidal signals. Therefore, the JTRF2020 UT1 and LOD values, which are available here, include the anomalous tidal signals and should not be used. The JTRF2020 UT1 and LOD values will be replaced by corrected values once they are available.

About JTRF2020 EOPs

Earth Orientation Parameters (EOPs) are concomitantly adjusted with station positions and the Helmerts. In our combination scheme, the daily station positions derived from the four space-geodetic techniques are assimilated along with EOPs and, when available, site tie observations. Each aggregated SINEX file available from sideshow contains the daily station positions and their full covariance matrix. The EOPs (values and uncertainties for polar motion, polar motion rate, UT1, and LOD) are available from the table below. The EOPs are given at daily intervals although gaps exist in the time series especially in the early years of the JTRF2020 solution.

The table below only shows EOP data from every 10th record. To view the FULL EOP data, use the download button below or use one of the commands in the Download All EOP Commands section below. To view EOP plots, see the next section.  To download all EOP plots, see the Download All EOP Commands section below.

JTRF2020 EOP Series
JTRF2020 EOP Series
Note: The table below only shows data from EVERY 10TH RECORD. To view and download the FULL table data, use the download button above. Use the arrows at the top to sort each column. If you have any questions or inquiries, please contact us.

Download All EOP Commands

Via wget command
  • EOP data
    • wget https://www.jpl.nasa.gov/site/jsgt/jtrf/pub/latest/values/eop/data/jtrf2020_defining_eop_noon.txt
  • EOP plots
    • wget https://www.jpl.nasa.gov/site/jsgt/jtrf/pub/latest/values/eop/plots/jtrf2020_defining_eop_plot_archive_all.tar.gz
Via curl command
  • EOP data
    • curl https://www.jpl.nasa.gov/site/jsgt/jtrf/pub/latest/values/eop/data/jtrf2020_defining_eop_noon.txt ––output ‘jtrf2020_noon.eop’ -k
  • EOP plots
    • curl https://www.jpl.nasa.gov/site/jsgt/jtrf/pub/latest/values/eop/plots/jtrf2020_defining_eop_plot_archive_all.tar.gz ––output ‘jtrf2020_eop_plots.tar.gz’ -k
